Scroll to the right to view the specifications
1.Chip Terminations and Surface Mount Chip Terminations
|
额定功率 |
频率范围 |
最大驻波比 |
尺寸 |
产品型号 |
|||||
|
Power Rating |
Frequency |
VSWR |
Dimensions(mm) |
Model |
|||||
|
（W） |
(GHz) |
(Max) |
W |
L |
H |
A |
B |
C |
Click below to view specifications |
|
2
|
DC-12 | 1.30 | 0.7 | 1.1 | 0.25 |
N/A |
N/A |
N/A |
RFR50-2CT49701A-J |
|
16
|
DC-12 |
1.40 |
1.1 |
1.8 |
0.38 |
N/A |
N/A |
N/A |
RFR50-16CT67201A-J |
|
10
|
DC-18 |
1.35 | 1.27 | 2.54 | 0.38 |
N/A |
N/A |
N/A |
RFR50-2CT43701A-J |
|
45 |
DC-8 |
1.20 |
1.6 |
3.2 |
0.38 |
N/A |
N/A |
N/A |
RFR50-45CT25301A-J |
|
15
|
DC-6 |
1.25 |
2 | 4 | 0.635 | N/A | N/A | N/A | RFR50-15CT67701A-J |
| 20 | DC-12 |
1.25(DC-6.5GHz) 1.30(8-12GHz)
|
2.5 | 5 | 0.6 | N/A | N/A | N/A |
RFR50-20CT0454A-J |
|
125
|
DC-14 |
1.40 |
3.33 | 2.76 | 0.38 |
N/A |
N/A |
N/A |
RFR50-125CT49201A-J |
|
150
|
DC-3.5 |
1.50 | 5.2 | 6.35 | 0.38 |
N/A |
N/A |
N/A |
RFR50-150CT46601A-J |
|
100
|
DC-3.5 |
1.50 |
5.8 |
3 |
0.635 |
N/A |
N/A |
N/A |
RFR50-100CT49601A-J |
|
100
|
DC-3.5 | 1.50 | 6.35 | 3 | 0.635 |
N/A |
N/A |
N/A |
RFR50-100CT46802A-J |
|
100
|
DC-3.5 |
1.40 |
8 | 7 | 1 | N/A | N/A | N/A | RFR50-100CT66401A-J |
|
400
|
DC-0.5 |
1.20 | 10 | 6 | 1.5 | N/A | N/A | N/A | RFR50-400CT2804A-J |
|
500
|
DC-1 |
1.25 | 12.7 |
12.7 |
2 |
N/A |
N/A |
N/A |
RFR50-500TWM2724-J |
2.Chip Resistors and Surface Mount Chip Resistors
|
额定功率 |
频率范围 |
最大驻波比 |
尺寸 |
产品型号 |
|||||
|
Power Rating |
Frequency |
VSWR |
Dimensions（mm) |
Model |
|||||
|
(w) |
(GHz) |
(Max) |
W |
L |
T |
H |
I |
Tw |
Click below to view specifications
|
|
2 |
DC-18 |
|
0.8 | 1.6 | 0.4 | 0.4 | N/A | N/A | RFR100-2CR8002B-J |
|
4 |
1.25 | 2 | 0.35 | 0.38 | N/A | RFR130-4CR14303A-J | |||
Suggested mounting procedures:
1.Solder part or leads in place with controlled
temperature iron (260℃).
Drill thermal vias through PCB and f
