单电极贴片电阻(Chip Terminations and Surface Mount Chip Terminations)



返回列表   我要定制

现有产品满足不了需求?

浏览产品规格书请划到右侧

额定功率

频率范围

最大驻波比

尺寸

产品型号

Power Rating

Frequency

VSWR

Dimensions(mm)

Model

(W)

(GHz)

(Max)

W

L

H

A

B

C

点击下方查看规格书

1



DC-30

≤1.25:1(DC-28GHz)

≤1.30:1(DC-30GHz)

0.5 1 0.25 N/A
N/A
N/A

2



DC-12 1.20
1.1 0.7 0.25 N/A
N/A
N/A

3



DC-6
1.28 1.27 2 0.6 N/A
N/A
N/A

RFR50N-3CT47701A

10



DC-3
1.20 1.27 2.54 0.6 N/A N/A
N/A
RFR50N-10CT2203A

12



DC-6

≤1.22:1(DC-4GHz)

≤1.28:1(DC4-6GHz)

1.5 3 0.38 N/A
N/A
N/A

20



DC-2.2
1.20
2.2 2 0.4 N/A
N/A
N/A

5



DC-12 1.35 2.5 3 0.4 N/A N/A N/A

20



DC-6
1.20 2.5 5 0.6 N/A
N/A
N/A


20



DC-12 1.40 3
2.5 0.6 N/A
N/A
N/A
RFR50-20CT0215A

20



DC-3 1.20 4 4 1 N/A N/A N/A RFR50N-20CT0706A

20



DC-18

1.35

5

2.5

0.6

N/A

N/A

N/A

RFR50-20CT0406A


20


DC-6
1.20
5
2.5
0.6 N/A
N/A
N/A
RFR50N-20CT0430A


80


DC-6

1.25

5 5 1 N/A N/A N/A

RFR50N-80CT5901A


40



DC-3 1.20 6 4.7 1 N/A N/A N/A RFR50-40CT0906A


100



DC-3
1.25
6.35
6.35
1 N/A
N/A
N/A


50


DC-7.2
1.25
7 3.7 1 N/A
N/A
N/A
FR50-50CT0502A


100


DC-3

1.15

8.9

5.7

1

N/A

N/A

N/A

RFR50N-100CT4503A


250



DC-2.7

1.25

9.5 5.7 1 N/A N/A N/A

RFR50N-250CT9402A


200


DC-1
1.15
9.5
6.35
1 N/A
N/A
N/A
RFR50-200CT4710A


250



DC-3

1.20

9.5

9.5

1

N/A

N/A

N/A

RFR50N-250CT2525A

建议安装方法:

1、 在焊接器件或引线时,最好用控温烙铁,温度保持在260℃。

2、 PCB板上要钻散热孔,并在散热孔中填充焊料。

Suggested mounting procedures:

1.Solder part or leads in place with controlled

temperature iron (260).

2.Drill thermal vias through PCB and fill with solder.
